sheet steel, galvanised, insulation: Class B
Protection of overload, overvoltage, locked-rotor and polarity, tachoutput, 0-10V pwm speed control, waterproof: IP44
Coolcom Forward Curved DC centrifugal fans offer exceptional airflow and pressure performance with a variety of voltage, speed control, and alarm output options.
| Model | Size(mm) | Bearing Type | Rated Voltage(V) | Current(A) | Speed(RPM) | Air Flow(CMF) | Pressure(mmH2O) | Noise(db) | Weight(g) | Buy it now |
|---|---|---|---|---|---|---|---|---|---|---|
| CM12062CB12MF | 120*62 | 2 balls | 12 | 3.8 | 2500 | 176 | 522.5 | 60 | 800 | |
| CM12062CB12LF | 120*62 | 2 balls | 12 | 2.3 | 2200 | 155 | 405 | 57 | 800 | |
| CM12062CB24HF | 120*62 | 2balls | 24 | 2.4 | 2800 | 197 | 653 | 63 | 800 | |
| CM12062CB24MF | 120*62 | 2balls | 24 | 1.7 | 2500 | 176 | 522.5 | 60 | 800 | |
| CM12062CB24LF | 120*62 | 2 balls | 24 | 1.1 | 2200 | 155 | 405 | 57 | 800 | |
| CM12062CB48HF | 120*62 | 2 balls | 48 | 1.2 | 2800 | 197 | 653 | 63 | 800 | |
| CM12062CB48MF | 120*62 | 2 balls | 48 | 0.8 | 2500 | 176 | 522.5 | 60 | 800 | |
| CM12062CB48LF | 120*62 | 2 balls | 48 | 0.5 | 2200 | 155 | 405 | 57 | 800 |
