PBT with 30% glass filled UL94-V0
RD,tach output, PWM speed control, temperature control ,locked-rotor,polarity,waterproof
large air value with low noise level ,long life span with stable quality, available for voltage range 24V,12V and 05V
| Model | Size(mm) | Bearing Type | Rated Voltage(V) | Current(A) | Speed(RPM) | Air Flow(CMF) | Pressure(mmH2O) | Noise(db) | Weight(g) | Buy it now |
|---|---|---|---|---|---|---|---|---|---|---|
| CM7530KB24U | 75*75*30 | ball or sleeve | 24 | 0.3 | 4200 | 13.4 | 11.57 | 40 | 76g | |
| CM7530KB24H | 75*75*30 | ball or sleeve | 24 | 0.16 | 3000 | 10.3 | 8.89 | 38.5 | 76g | |
| CM7530KB24M | 75*75*30 | ball or sleeve | 24 | 0.13 | 2500 | 7.5 | 5.35 | 33.6 | 76g | |
| CM7530KB24L | 75*75*30 | ball or sleeve | 24 | 0.1 | 2000 | 6 | 3.42 | 26.8 | 76g | |
| CM7530KB12U | 75*75*30 | ball or sleeve | 12 | 0.5 | 4200 | 13.4 | 11.57 | 40 | 76g | |
| CM7530KB12H | 75*75*30 | ball or sleeve | 12 | 0.32 | 3000 | 10.3 | 8.89 | 38.5 | 76g | |
| CM7530KB12M | 75*75*30 | ball or sleeve | 12 | 0.2 | 2500 | 7.5 | 5.35 | 33.6 | 76g | |
| CM7530KB12L | 75*75*30 | ball or sleeve | 12 | 0.16 | 2000 | 6 | 3.42 | 26.8 | 76g | |
| CM7530KB05H | 75*75*30 | ball or sleeve | 05 | 0.5 | 3000 | 10.3 | 8.89 | 38.5 | 76g | |
| CM7530KB05M | 75*75*30 | ball or sleeve | 05 | 0.28 | 2500 | 7.5 | 5.35 | 33.6 | 76g | |
| CM7530KB05L | 75*75*30 | ball or sleeve | 05 | 0.18 | 2000 | 6 | 3.42 | 26.8 | 76g |
