PBT with 30% glass filled UL94-V0
tachometer output or locked rotor alarm signal; PWM speed control
Coolcom burshless DC axial fans with large air flow value , low noise level and long life span , voltage available for 12v ,24v and 48v .provide many optional function to meet with customer's rquirement
| Model | Size | Bearing Type | Rated Voltage | Current | Speed | Air Flow | Pressure | Noise | Weight | Buy it now |
|---|---|---|---|---|---|---|---|---|---|---|
| CM8025AS12X | 80*25 | ball or sleeve | 12 | 0.26 | 4000 | 51.23 CFM | 8.49 mmAq | 38.80 | 85g | |
| CM8025AS12L | 80*25 | ball or sleeve | 12 | 0.36 | 5000 | 63.72 CFM | 13.14 mmAq | 44.5 | 85g | |
| CM8025AS12M | 80*25 | ball or sleeve | 12 | 0.66 | 6000 | 76.22 CFM | 18.80 mmAq | 50.20 | 85g | |
| CM8025AS12H | 80*25 | ball or sleeve | 12 | 1.00 | 7000 | 88.72 CFM | 25.46 mmAq | 55.70 | 85g | |
| CM8025AS12U | 80*25 | ball or sleeve | 12 | 1.24 | 8000 | 101.21 CFM | 33.15 mmAq | 58.5 | 85g | |
| CM8025AS24X | 80*25 | ball or sleeve | 24 | 0.13 | 4000 | 51.23 CFM | 8.49 mmAq | 38.8 | 85g | |
| CM8025AS24L | 80*25 | ball or sleeve | 24 | 0.16 | 5000 | 63.72 CFM | 13.14 mmAq | 44.5 | 85g | |
| CM8025AS24M | 80*25 | ball or sleeve | 24 | 0.33 | 6000 | 76.22 CFM | 18.80 mmAq | 50.2 | 85g | |
| CM8025AS24H | 80*25 | ball or sleeve | 24 | 0.50 | 7000 | 88.72 CFM | 25.46 mmAq | 55.7 | 85g | |
| CM8025AS24U | 80*25 | ball or sleeve | 24 | 0.62 | 8000 | 101.21 CFM | 33.15 mmAq | 58.5 | 85g | |
| CM8025AS48X | 80*25 | ball or sleeve | 48 | 0.06 | 4000 | 51.23 CFM | 8.49 mmAq | 38.8 | 85g | |
| CM8025AS48L | 80*25 | ball or sleeve | 48 | 0.08 | 5000 | 63.72 CFM | 13.14 mmAq | 44.5 | 85g | |
| CM8025AS48M | 80*25 | ball or sleeve | 48 | 0.16 | 6000 | 76.22 CFM | 18.80 mmAq | 50.2 | 85g | |
| CM8025AS48H | 80*25 | ball or sleeve | 48 | 0.25 | 7000 | 88.72 CFM | 25.46 mmAq | 55.7 | 85g | |
| CM8025AS48U | 80*25 | ball or sleeve | 48 | 0.31 | 8000 | 101.21 CFM | 33.15 mmAq | 58.5 | 85g |
