PBT with 30% glass filled UL94-V0
tachometer output or locked rotor alarm signal; PWM speed control
Coolcom burshless DC axial fans with large air flow value , low noise level and long life span , voltage available for 12v ,24v and 48v .provide many optional function to meet with customer's rquirement
| Model | Size | Bearing Type | Rated Voltage | Current | Speed | Air Flow | Pressure | Noise | Weight | Buy it now |
|---|---|---|---|---|---|---|---|---|---|---|
| CM8015AS05L | 80*15 | ball or sleeve | 05 | 0.18 | 1500 | 16.5 CFM | 0.80 mmAq | 26.6 | 38g | |
| CM8015AS05M | 80*15 | ball or sleeve | 05 | 0.22 | 2000 | 21.6 CFM | 1.4 mmAq | 28.9 | 38g | |
| CM8015AS05H | 80*15 | ball or sleeve | 05 | 0.36 | 2500 | 26.7 CFM | 2.2 mmAq | 32.1 | 38g | |
| CM8015AS12L | 80*15 | ball or sleeve | 12 | 0.08 | 1500 | 16.5 CFM | 0.80 mmAq | 26.6 | 38g | |
| CM8015AS12M | 80*15 | ball or sleeve | 12 | 0.1 | 2000 | 21.6 CFM | 1.4 mmAq | 28.9 | 38g | |
| CM8015AS12H | 80*15 | ball or sleeve | 12 | 0.14 | 2500 | 26.7 CFM | 2.2 mmAq | 32.1 | 38g | |
| CM8015AS12U | 80*15 | ball or sleeve | 12 | 0.22 | 3000 | 31.9 CFM | 3.1 mmAq | 37.3 | 38g | |
| CM8015AS24L | 80*15 | ball or sleeve | 24 | 0.05 | 2000 | 21.6 CFM | 1.4 mmAq | 28.9 | 38g | |
| CM8015AS12M | 80*15 | ball or sleeve | 24 | 0.07 | 2500 | 26.7 CFM | 2.2 mmAq | 32.1 | 38g | |
| CM8015AS12H | 80*15 | ball or sleeve | 24 | 0.11 | 3000 | 31.9 CFM | 3.1 mmAq | 37.3 | 38g |
