PBT with 30% glass filled UL94-V0
tachometer output or locked rotor alarm signal; PWM speed control
Coolcom burshless DC axial fans with large air flow value , low noise level and long life span , voltage available for 12v ,24v and 48v .provide many optional function to meet with customer's rquirement
| Model | Size | Bearing Type | Rated Voltage | Current | Speed | Air Flow | Pressure | Noise | Weight | Buy it now |
|---|---|---|---|---|---|---|---|---|---|---|
| CM7010AB24H | 70*10 | ball or sleeve | 24V | 0.11 | 3500 | 19.13 cfm | 2.65 mmH2O | 32.6 | 27g | |
| CM7010AB24M | 70*10 | ball or sleeve | 24V | 0.09 | 3000 | 16.39 cfm | 2.48 mmH2O | 27.9 | 27g | |
| CM7010AB24L | 70*10 | ball or sleeve | 24V | 0.07 | 2500 | 13.31 cfm | 1.28 mmH2O | 23.9 | 27g | |
| CM7010AB12H | 70*10 | ball or sleeve | 12V | 0.2 | 3500 | 19.13 cfm | 2.65 mmH2O | 32.6 | 27g | |
| CM7010AB12M | 70*10 | ball or sleeve | 12V | 0.14 | 3000 | 16.39 cfm | 2.48 mmH2O | 27.9 | 27g | |
| CM7010AB12L | 70*10 | ball or sleeve | 12V | 0.1 | 2500 | 13.31 cfm | 1.28 mmH2O | 23.9 | 27g |
