material : steel, aluminum
RD, PWM,FG, water proof, dust proof,
COOLCOM AC Axial fan with absolutely advantages on noise, air value and effciency , offering provides many options to meet your thermal management requirements. option function including : 1. multiple voltage applicatrion; 2, Environmental protection options available including conformal coating or IP55 encapsulation; 3. High temperature models for operation up to 90 degrees C. 4. Custom designs welcome.
| Model | Size(mm) | Bearing Type | Rated Voltage(V) | Current(A) | Speed(RPM) | Air Flow(CMF) | Pressure(mmH2O) | Noise(db) | Weight(g) | Buy it now |
|---|---|---|---|---|---|---|---|---|---|---|
| CM17251AB01H | 172*51 | ball bearing | 100/125,50/60Hz | 0.50/0.45 | 2700/3100 | 190/235CFM | 45/50 | |||
| CM17251AB02H | 172*51 | ball bearing | 200/240,50/60Hz | 0.22/0.21 | 2700/3100 | 190/235CFM | 45/50 | |||
| CM17251AB03H | 172*51 | ball bearing | 380/420V,50Hz | 0.11 | 2700 | 190CFM | 45 | |||
| CM17251AB01M | 172*51 | ball bearing | 100/125,50/60Hz | 0.41/0.39 | 2400/2300 | 170/160CFM | 41/40 | |||
| CM17251AB02M | 172*51 | ball bearing | 200/240,50/60Hz | 0.19/0.18 | 2400/2300 | 170/160CFM | 41/40 | |||
| CM17251AB03M | 172*51 | ball bearing | 380/420V,50Hz | 0.09 | 2400 | 170CFM | 41 | |||
| CM17251AB01L | 172*51 | ball bearing | 100/125,50/60Hz | 0.35/0.35 | 1900/1500 | 125/105CFM | 32/30 | |||
| CM17251AB02L | 172*51 | ball bearing | 200/240,50/60Hz | 0.16/0/.16 | 1900/1500 | 125/105CFM | 32/30 | |||
| CM17251AB03L | 172*51 | ball bearing | 380/420V,50Hz | 0.07 | 1900 | 125CFM | 32 |
