material : steel, aluminum
RD, PWM,FG, water proof, dust proof,
COOLCOM AC Axial fan with absolutely advantages on noise, air value and effciency , offering provides many options to meet your thermal management requirements. option function including : 1. multiple voltage applicatrion; 2, Environmental protection options available including conformal coating or IP55 encapsulation; 3. High temperature models for operation up to 90 degrees C. 4. Custom designs welcome.
| Model | Size(mm) | Bearing Type | Rated Voltage(V) | Current(A) | Speed(RPM) | Air Flow(CMF) | Pressure(mmH2O) | Noise(db) | Weight(g) | Buy it now |
|---|---|---|---|---|---|---|---|---|---|---|
| CM14045AB01H | 140*45 | ball | 100/125V, 50/60Hz | 0.35 | 2800/3400 | 160/185 CFM | 48/56 | 460g | ||
| CM14045AB02H | 140*45 | ball | 200/240V, 50/60Hz | 0.13/0.14 | 2800/3300 | 160/185 CFM | 48/56 | 460g | ||
| CM14045AB01M | 140*45 | ball | 100/125V, 50/60Hz | 0.28 | 2400/2800 | 156/182 CFM | 44/50 | 460g | ||
| CM14045AB02M | 140*45 | ball | 200/240V, 50/60Hz | 0.14 | 2400/2800 | 156/182 CFM | 44/50 | 460g |
