Metal aluminum Sheet
Motor type : EC brushless external rotor motor
Optional voltage : AC 115v/230v
Speed Control : 0-10V / PWM control
Speed : 1900rpm,Customizable according to customer requirements
Certifications: UL, CE, E306337
Insulation Class: Class B
The model work voltage is AC 115V / 230V.
Diameter size is 355mm, impeller height 120mm, total height with motor base is 1230mm.
Support 0-10 VDC or PWM speed control.
50,000 hours continuous operating at 40℃.
One piece wheel (6 blades).
| Model | Rated Voltage | Operating Voltage | Rated Current(A) | Rated Power(w) | Rated Speed(rpm) | Air Flow(cfm) | Pressure(mmH20) | Noise(db) | Weight(kg) | Buy it now |
|---|---|---|---|---|---|---|---|---|---|---|
| CM355170CH01B-EC | 115V,60Hz | 92V-132V | 6.7 | 480 | 1930 | 2346 | 77.15 | 76 | 5.8 | |
| CM355170CH02B-EC | 230V,50Hz | 184V-265V | 3.4 | 480 | 1930 | 2346 | 77.15 | 76 | 5.8 |
